Kystar KLS2c three-in-one controller is a two-network-port three-in-one controller thatintegrates professional video processor, LED sending card and offline player for LEDdisplaysolutions. One device can easily handle large screens, greatly simplifyingLEDsolutionconfiguration and on-site debugging.

Features
 The single machine has 2 network ports, and the maximum load capacity of thewholemachine is 1.31 million pixels, the width can reach 4096 points, and the height canreach 2048 points.
 Supports multiple digital signal interfaces, including 2*HDMI1.3, 1*DVI-Dand1*USB.
 Supports arbitrary stringing, the network port load is not restricted by rectangle, andtheutilization rate of the network port is improved .
 Supports USB playback and perfectly supports multiple video and picture formats.
 EDID configuration management: supports reading, modifying and customizingEDID(Extended Display Identification Data).
 Supports one-key freeze function.
 Supports output of various test screens such as pure color, gradient, scan line, etc.
 Black edge removal/cropping function: solve the black edge problemgeneratedbythefront-end signal and perform arbitrary cropping on any signal source (still keepingthefull screen state).
 Support key lock to prevent accidental operation.
 The brightness and contrast of the overall output image can be adjusted inreal timeandquickly.
