With 9 channels of amplification, up to 4 independent subwoofers, Dolby Atmos and DTS:X, plus IMAX Enhanced and Auro-3D, the AVC-X3800H envelops larger living spaces in theatre-quality sound. Enjoy amazing 8K video quality and with HEOS® Built-in, wirelessly stream and share online music between rooms.
Enveloping 3D audio
Feel like you’re in the centre of the action with enveloping 3D sound.
Expert ready
You’ll be amazed at the available configuration options to best fit your space.
Geared for 8K
Enjoy amazing video quality from the latest 8K technology available.
Optimize your room
Enhance performance with room correction options from Audyssey (installed) or Dirac Live (optional upgrade available with future SW update).
High performance 9-channel amplifier
Discrete high-current amplifiers deliver up to 180W per channel – enough power to drive any speaker.
3D audio experience
Get enveloped in sound with Dolby Atmos®, DTS:X®, IMAX Enhanced and Auro-3D, along with Dolby Surround, DTS Neural:X and Auro-Matic upmixer to optimize legacy content.
Configuration flexibility
AVC-X3800H offers many setup options and flexibility to adjust your home theatre to meet your needs. Supports
Advanced 8K home theatre
8K video is supported on all six HDMI inputs and two of the three outputs. Enjoy easy video compatibility and great picture quality with HLG, HDR, Dolby Vision, HDR10+, and Dynamic HDR passthrough.
| Feature | Support |
|---|---|
| DTS-HD Master Audio | Yes |
| DTS:X | Yes |
| DTS:X Pro | No |
| DTS Neo:X | No |
| DTS Neural:X | Yes |
| DTS Virtual:X | Yes |
| IMAX Enhanced | Yes |
| Dolby TrueHD | Yes |
| Dolby Atmos | Yes |
| Dolby Atmos Height Virtualization | Yes |
| Dolby Atmos Music | Yes |
| Dolby ProLogic IIz | No |
| Dolby Surround | Yes |
| Auro-3D | Yes |
| 360 Reality Audio | Yes |
| MPEG-H | Yes |
| Multichannel Stereo | Yes |
| Maximum Processing Channels | 11.4 |
| Feature | Details |
|---|---|
| Discrete Power Amplifier | Yes |
| Power Output (8 Ω, 2ch) |
105 W (20 Hz – 20 kHz, 0.08% THD) |
| Power Output (6 Ω, 2ch) |
135 W (1 kHz, 0.7% THD) |
| Power Output (6 Ω, 1ch) |
180 W (1 kHz, 10% THD) |
| Feature | Support |
|---|---|
| Media Server | Yes |
| HEOS Wireless Multi-Room Technology | Yes |
| Alexa Voice Assistant | Yes |
| Google Voice Assistant | Yes |
| Apple HomePod Support | Yes |
| AirPlay 2 | Yes |
| TuneIn | Yes |
| Spotify Connect | Yes |
| Roon Tested | Yes |
| HEOS App Control | Yes |
| Smartphone App | Denon 2016 AVR Remote |
| Format | Support |
|---|---|
| MP3 | Yes |
| WMA | Yes |
| AAC | Yes |
| FLAC | Yes |
| ALAC | Yes |
| WAV | Yes |
| FLAC HD (192kHz / 24-bit) | Yes |
| WAV (192kHz / 24-bit) | Yes |
| ALAC (192kHz / 24-bit) | Yes |
| DSD Audio Streaming | Yes (2.8 / 5.6 MHz) |
| Feature | Support |
|---|---|
| Ethernet Port | Yes |
| Wi-Fi | Yes |
| Bluetooth | Yes |
| Feature | Details |
|---|---|
| Maximum Dimensions (W × D × H) | 43.4 × 34.0 × 16.7 cm |
| Weight | 9.5 kg |
