| Feature | Details |
|---|---|
| Rated Output Power (2-Channel Driving, CD → SP OUT) |
80 W + 80 W (8 Ω, 20 Hz – 20 kHz, THD 0.07%) 160 W + 160 W (4 Ω, 1 kHz, THD 0.7%) |
| Total Harmonic Distortion | 0.01% (Rated Output: –3 dB), 8 Ω, 1 kHz |
| Output Terminals |
Speaker A or B: 4 – 16 Ω Speaker A + B: 8 – 16 Ω Suitable for Stereo Headphones |
| Input Sensitivity / Impedance (EXT.PRE) | 1.0 V / 15 kΩ |
| Amplification Factor | 28 dB |
| Feature | Details |
|---|---|
| PHONO (MM) Input Sensitivity / Impedance | 2.5 mV / 47 kΩ |
| PHONO (MC) Input Sensitivity / Impedance | 200 μV / 100 Ω |
| CD / NETWORK-AUX / RECORDER Input | 150 mV / 15 kΩ |
| RIAA Deviation | PHONO: 20 Hz – 20 kHz ±0.5 dB |
| Maximum Input (PHONO MM) | 130 mV / 1 kHz |
| Maximum Input (PHONO MC) | 10 mV / 1 kHz |
| Feature | Details |
|---|---|
| Signal-to-Noise Ratio (PHONO MM) |
89 dB (Input terminals short-circuited, 5 mV input signal) |
| Signal-to-Noise Ratio (PHONO MC) |
74 dB (Input terminals short-circuited, 0.5 mV input signal) |
| Signal-to-Noise Ratio (CD / NETWORK-AUX / RECORDER) | 107 dB (Input terminals short-circuited) |
| Frequency Response | 5 Hz – 100 kHz (0 to -3 dB) |
| Tone Control – Bass | 100 Hz ±8 dB |
| Tone Control – Treble | 10 kHz ±8 dB |
| Feature | Details |
|---|---|
| Format | Digital Audio Interface (Linear PCM) |
| Coaxial Input | 0.5 Vp-p / 75 Ω |
| Optical Input | More than -27 dBm |
| Optical Wavelength | 660 nm |
| Feature | Details |
|---|---|
| Operating Temperature | +5°C to +35°C |
| Power Supply | AC 230 V, 50/60 Hz |
| Power Consumption | 400 W |
| Standby Consumption (TV Auto Play Enabled) | 0.4 W |
| Standby Consumption (TV Auto Play Disabled) | 0.2 W |
