| Feature | Details |
|---|---|
| Power Amplifiers | 5 Channels (Front L/R, Center, Surround L/R) |
| Power Output (1ch Driven) |
130 W per channel (6Ω, 1kHz, THD 1%) |
| Power Output (2ch Driven) |
90 W per channel (6Ω, 1kHz, THD 0.7%) |
| Power Output (2ch Driven Full Range) |
70 W per channel (8Ω, 20Hz – 20kHz, THD 0.08%) |
| Speaker Impedance | 4 – 16 Ω |
| Feature | Details |
|---|---|
| Input Sensitivity / Impedance | 200 mV / 47 kΩ |
| Frequency Response |
10 Hz – 100 kHz (+1, -3 dB, DIRECT Mode) |
| Signal-to-Noise Ratio |
98 dB (IHF-A Weighted, DIRECT Mode) |
| Band | Frequency Range |
|---|---|
| FM | 87.5 – 108 MHz |
| AM | 522 kHz – 1611 kHz |
| Feature | Details |
|---|---|
| Power Supply | AC 230V, 50Hz |
| Power Consumption | 330 W |
| Standby Power Consumption | 0.1 W |
| CEC Standby Consumption | 0.5 W |
| No-Sound Power Consumption (ECO On / Off) | 30 W / 45 W |
| Dimensions (W × H × D) | 434 × 151 × 319 mm |
| Weight | 7.5 kg |
